Manure Spreader

The manure spreader by Paddock Machinery is one of our most popular tow behind spreaders. It’s heavy duty construction, combined with high capacity yet good maneuverability lends it to a range of users. Ideal for horse stables, large scale farms, hobby farms and acreages through to use by professional landscapers. Capable of spreading a range of manures and dungs even with a high soil mix. Great for horse, sheep, pig and cow manure to name a few. This twin wheel drive manure spreader is reliable and built tough to last in Australian conditions. Maintenance is simple and it can be used with many vehicles from ATVs, quad bikes through to utes or tractors via the universal clevis hitch.

‘Paddock’ Tow Behind Manure Spreader

• Use to distribute a range of manures and soil mixes
• Great for horse, cattle, sheep dung to name a few
• Tow behind quad bikes, four wheelers, ATVs, tractors, utilities
• Uses a clevis tow hitch (can be used with tow ball hitches by removing the ball)
• High maneuverability to access tight areas
• Suitable for in stall loading
• Replaceable, wide spread beaters
• Low maintenance

Manure Spreader Features & Functionality

The Paddock manure spreader is easy to use. Connect to the clevis hitch with a range of vehicles from ATVs, quad bikes, four wheelers, utes and tractors. If your vehicle has a tow ball hitch the ball can be removed and the hitch pin dropped through the hole. The hitch height can also be adjusted to give a better ride height.

The spreader is wheel driven – with both engagement levers down it will free wheel as you drive forward. There is also a transport tail gate, which when lowered, prevents any manure entering the beaters. To start spreading, engage both hand levers. The wheels will drive the chains and start moving the conveyer (engagement lever 1) and the beater paddles (engagement lever 2). The manure will be slowly fed into the beaters which will pulverise and broadcast the mix out of the back of the spreader. When finished spreading, simply lower the transport tail gate and disengage both levers.

T-Rod Web Chains -The floor conveyor is driven by t-rod web chains designed to give up to three times the life of other chains.

Paddle Beaters – Paddle beaters have easy access, long life bearings making maintenance a piece of cake. These are also replaceable.

Jockey Wheel – Included is a 2000lb jockey wheel giving easy movement of the spreader. This swings away when the spreader is connected to the towing vehicle.

Transport Tail Gate – A transport tailgate can be raised or lowered and incorporates two rubber bump stops. This prevents the manure entering the beaters when you are not wanting to spread or transporting the unit.

Drive Wheels – Wheel driven, there are two control levers. One lever engages and disengages the beater paddles while the other engages the floor conveyor.

Beware!There are many cheap knock-off ATV manure spreaders on the market. PADDOCK units are exceptional quality with loads of units in use around Australia. Come and compare to spot the differences.

Paddock Manure Spreader Specifications

Spreader Model	PATVMANS01
Hopper Volume	820L (29 cubic feet)
Work Rate	2-5 Tonne /hr
Tow Speed	5 – 8 km/hr
Spread Width	up to 120cm
No. of Beaters	8 (replaceable)
Beater Width	700mm
Beater Diameter	460mm (18″)
Construction	Heavy duty 12 Gauge steel construction. High density poly vinyl floor.
Size	290cm (L) x 110cm (W) x 77cm (H)
Weight	230kg
Wheels	High traction, puncture resistant tyres. 12″x 6-4 Bolt / 6-12 Hub to Hub spacing is 1200mm
Attachment / Linkage	Adjustable universal clevis hitch pin (Can be used with tow ball hitches)
Features	Two wheel chain drive Jockey wheel included Adjustable tow hitch Replaceable paddle blades Ground drive ‘Bear Claw’ Beaters
Brand	Paddock Machinery
Warranty	12 Months Manufacturer’s Warranty

Shipping: We can ship Australia wide but due to the size and weight of the manure spreader it is recommended you contact us for a freight quote to your location before ordering.

Note: This manure spreader requires some assembly. All major components have been pre assembled for you and only requires basic tools.
