GERNI Mini Hot Professional 3 Phase Hot Water Pressure Washer Page For Info Only

GERNI “Mini Hot” 3 Phase Hot Water Pressure Washer – Information page only

Partslist Here

THIS MACHINE HAS NOT BEEN AVAILABLE FOR A LONG TIME, so only a FEW replacement parts are available so check the pdf drawing and Contact Us with EVERY SINGLE PART NUMBER YOU THINK YOU MAY NEED for its availability. Otherwise choose a replacement machine from below!

The GERNI Mini Hot compact hot water pressure washer machines were constructed for professional use with guaranteed motor and pump quality. Used for hot water cleaning in both the light Industrial and the commercial sector, farming and light industrial sector.

SAFETY FEATURES FOR Gerni Mini Hot

• Overload Protector – Thermal switches in the pump motor housing will protect the motor against overheating.
• Built in Safety Valves – If the water pressure exceeds the normal working pressure the safety valve will open the by-pass and thereby prevent damage to the high pressure cleaner.
• Flow switches – should the water be turned off and the pressure cleaner is running the flow switch is activated and stops the pressure cleaner before any damage can occur.
• Gerni Patented By-pass System – When the unit is operating and the pistol is released the by-pass system is activated. When activated there is no pressure left in the hose, pistol, or lance itself making the unit not only the safest system available but also very user friendly.
• Gerni Pumps – Axial Piston Pump, driven by a power source through a cam disc sometimes called a ‘wobble or swash plate’. This is the most efficient and the style used in all Gerni manufactured pumps. Everything is in line, resulting in minimum friction loss and requiring a smaller power source.
• Optional extra Gerni Patented Turbo Laser Lance – Individual water drops are 10 times larger and 1000 times heavier than those from a traditional nozzle are. As a result, at a distance of 20cm the Gerni Turbo Laser spray retains 90% of its power while spray from a conventional nozzle retains only 15%.
• Low fuel level indicator – Protects against dry running of fuel pump.
• 0-voltage release – it is the safety mechanism against restart of the machine should there be a power failure.
• Water level control – the water level control disconnects the burner at too low a water level.
• Overheating Protector – Will stop the high-pressure cleaner if the diesel powered boiler temperature exceeds 140°C
• Flame control – Any combustion fault will cause the burner to be switched off after 10 seconds.

OPERATING INSTRUCTIONS

1. Don’t use turbo lance above 80 degrees (Opposite the off position on the main switch).

1. Don’t use a surface cleaner above 60 degrees

1. Check the fuel level before use.

1. Check the detergent container is full, and the dial turned off.

1. Pre-select the desired temperature.

1. If the steam is to be used, set the temperature to maximum and back off the steam dial which is found next to the pressure guage two turns anti-clockwise.

1. Then switch on the unit.

IMPORTANT

WHEN HOT WATER / STEAM HAS BEEN USED AND UNIT IS NOT BEING USED FOR AT LEAST 10 MINUTES, TURN THE TEMPERATURE DIALS DOWN AND FLUSH UNIT THROUGH WITH COLD WATER UNTIL THE LANCE IS COLD.

Hot water units should only be used for a maximum of 2 hour at a time before resting for at least one hour, with power and water supplies turned off.

Technical Data:

* Rated Voltage 415Volt 50Hz  3 Phase

* Pressure Bar PSI * Bar PSI Turbo Pressure ()

* Max temp. at max/min  80C/130/C  * Brass Pump Head

* Flow Rate:  Lit/min  * Cleaning Power; kW * Pump Speed; 2800RPM

* Fuel consumption 2.1l/h (/t=50tC)  * Hose: 10 meter

* Spectrum Lance * Optional Turbo Lance * Built-In Trolley

* Auto Stop/Start * Adjustable Detergent Injector * Can Be Wall Mounted

* Dimensions: 54cm Long x 59cm Wide x 78cm High Mass 72Kg

Check out the Nilfisk and Kerrick pressure washers below for a replacement machine shipped free, Australia-wide!
