Cub Cadet Z5 152 Zero-Turn Ride-On Mower

Technical Specification:

• Engine – Kawasaki FX850V OHV
• Engine displacement (cm3) – 852
• Rated power (kW/min-1) – 17,15 / 2,7
• Cylinders – V-TWIN dual cylinder
• Fuel tank capacity(l) – 2 x 34
• Lubrication – Pressure oil lubrication
• Drive – Dual Hydrostatic
• Transmission – Parker HTJ 12 cc
• Speed – 16 km/h (forward)/8 km/h (reverse)
• Control – Dual foot pedal control
• Mowing area (m2/h) – 15
• Cutting width – 152cm (60”)
• Cutting height – 26–127 mm
• Cutting options – 2-in-1
• Number of blades – 3
• Deck Engagement – Electric PTO
• Cutting height adjustment – 17 positions
• Deck wheels – 2 + Roller
• Mulch kit – Standard
• Grass bag capacity (l) – Side discharge
• Grass Deflector – Standard
• Rear bumper – Standard
• Turning radius (cm) – 0
• Wheels (front/rear) (Zoll) – 15 x 6 / 24 x 12
• Wheel bearings – Ball bearings
• Battery – 230 CCA
• Hourmeter / Serviceminder – Standard / Standard
• Safety systems – Rollover bar
• Seat type – High back with armrests, adjustable
• Seat adjustment – Quick adjuster lever
• Steering wheel – Soft-Grip
• Mow in reverse – Standard
• Noise values (dB) – 93 / 103 / 105
• Vibration value body (K-factor) (m/s2) – 1 / 0,5
• Vibration value hand-arm (K-factor) (m/s2) – 5 / 1,5
• Dimensions (L / W / H) (cm) – 230 / 160 / 134
• Weight net (kg) – 680
