Cub Cadet Ultima ZTXS 5 54 Zero Turn
$260.99
AVAILABLE SUMMER 2023Cub Cadet Ultima ZTXS 5 54 Zero TurnKohler Confidant ZT740/ 747ccSynchro-Steer™ technology offers 4-wheel control helps and provides stability for straight-line mowing on hillsides and slopes up to 20°SPECIFICATIONS: EngineAIR FILTERDual elementCHARGING SYSTEM12 amp regulatedCHOKEChoke-a-maticCYLINDERSTwinENGINE BRANDKohler®ENGINE DISPLACEMENT747ccENGINE MODELConfidantENGINE MODEL NUMBERZT740ENGINE OIL CAPACITY2.1 qt US ( 2 L)ENGINE STARTIgnition KeyFUEL…
AVAILABLE SUMMER 2023
Cub Cadet Ultima ZTXS 5 54 Zero Turn
Kohler Confidant ZT740/ 747cc
- Synchro-Steer™ technology offers 4-wheel control helps and provides stability for straight-line mowing on hillsides and slopes up to 20°
SPECIFICATIONS:
Engine
AIR FILTER
Dual element
CHARGING SYSTEM
12 amp regulated
CHOKE
Choke-a-matic
CYLINDERS
Twin
ENGINE BRAND
Kohler®
ENGINE DISPLACEMENT
747cc
ENGINE MODEL
Confidant
ENGINE MODEL NUMBER
ZT740
ENGINE OIL CAPACITY
2.1 qt US ( 2 L)
ENGINE START
Ignition Key
FUEL DELIVERY
Carburetor
FUEL GAUGE
Yes
FUEL TANK CAPACITY
5.5 gal. US (20.82 L)
GOVERNOR
Mechanical
ENGINE OUTPUT
25HP
LUBRICATION
Fully pressurized
OIL FILTER
Yes
STARTER TYPE
Electric
Cutting Deck
ANTI-SCALPING
Three gauge wheels
BLADE(S)
Three
CUTTING HEIGHT RANGE
1″ – 4.75″
DECK CONSTRUCTION
Fabricated
DECK CUTTING WIDTH
54 in
DECK ENGAGEMENT (PTO)
Electric
DECK LIFT
Foot pedal with Dial Adjust
DECK MATERIAL
10-gauge steel with 2-gauge reinforcement
DECK POSITIONS
17
DECK WASH
No
Comfort
ARMRESTS
Yes
SEAT ADJUSTMENT
Lever
SEAT TYPE
24″ high back
Battery
BATTERY
210 CCA
BATTERY TYPE
AGM (Absorbent Glass Mat)
BATTERY VOLTAGE
12V
Controls
BRAKES
Disc
CRUISE CONTROL
No
STEERING CONTROL
Steering Wheel
Warranty
COMMERCIAL WARRANTY
4-year 800 hours
DECK SHELL WARRANTY
Lifetime limited
FRAME WARRANTY
Lifetime Limited
WARRANTY
4-year 800 hours
Chassis
CORROSION PROTECTION
Yes
FRAME
1.5″ x 3″ tubular steel
REAR TOW HITCH
Yes
ROPS
Yes
TURNING RADIUS
0°
Additional Specifications
CUP HOLDER
Yes
HEADLIGHT(S)
Dual-LED
HOUR METER
Yes
MODEL NUMBER
47RTCAB7010
MULCH KIT
Available separately
OPERATOR PRESENCE SYSTEM
Yes
PARKING BRAKE
Foot Controlled
Disclaimers
SPECIFICATIONS
Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Drive System
DRIVE SYSTEM
Hydrostatic
FORWARD SPEED
8.5 MPH / 13.7 km/h
REVERSE SPEED
3.5 MPH / 5.6 km/h
TRANSMISSION
Hydro-Gear ZT 3200
Wheels
FRONT TIRES
13″x 6.5″-6″
REAR TIRES
23″x 12″-12″
TIRE TREAD
Turf Master / Multi Trac
Specifications
SERIES
Ultima Series™ ZTXS
