Cub Cadet Ultima ZTXS 4 60 Zero Turn

Cub Cadet Ultima ZTXS 4 60 Zero Turn

ONLINE ORDERS ONLY:
Mower Is Too Large To Fit On Lift Gate For Delivery- You must have a loading dock or forklift @ delivery location to unload.

FEATURES:

24HP/725cc Kohler 7000 Series V-Twin OHV 4-Cycle Engine

• Pressure lubrication increases engine life
• Consistent-Cut™ technology maintains engine speed
• Designed to run cooler and cleaner for longer

Dual Hydro-Gear™ ZT-3100™ Hydrostatic Drive System

• Delivers responsive maneuverability and a smoother ride
• Provides optimal torque and speeds up to 8 MPH

60-Inch, Fabricated (Welded) 3-Blade Mower Deck

• Features Cub Cadet’s best-in-class Aeroforce Max™ cutting system
• Top discharge deck allows for an elite bagging performance
• 17 cut heights ranging from 1″-4.75″
• Includes a lock-out position for transport

A Real Steel

• Durable squared tubular steel frame design
• Steel frame provides a better cut and trim quality
• Corrosion protected with a Triple Guard Corrosion Defense System™

Adjustable Lap Bars

• Accommodates riders of all shapes and sizes

Ultra-Premium High Back Seat w/ Cushioned Arm Rests

• Ergonomic, comfortable 20″ high-back seat with suspension
• Includes a ball-bearing seat slide and seat isolators
• Fully adjustable and optimized to reduce riders fatigue

Maintenance Made Easy

• Conveniently locate the battery under the seat
• Easily reach filters, spark plugs and oil with the open frame
• Removeable floorboard and easily access the external oil filter

Turf Master Tires

• Larger 22″ x 12″ tires provide excellent traction and a smoother ride
• Distribute weight evenly – great for uneven surface types
• Increased traction on slopes and in wet conditions

LED The Way

• Features dual-LED headlights for unmatched visibility in low light

Roll-Over-Protection (ROPS) Capable

• Provides additional safety benefits by reducing the risk of injury

SPECIFICATIONS:

Engine

AIR FILTER

Dual element

CHARGING SYSTEM

12 amp regulated

CHOKE

Choke-a-matic

CYLINDERS

Twin

ENGINE BRAND

Kohler®

ENGINE DISPLACEMENT

725cc

ENGINE MODEL

Pro 7000 series

ENGINE MODEL NUMBER

KT735

ENGINE OIL CAPACITY

2.0 qt. US (1.89 L)

ENGINE START

Ignition Key

FUEL DELIVERY

Carburetor

FUEL GAUGE

Yes

FUEL TANK CAPACITY

5.5 gal. US (20.82 L)

GOVERNOR

Mechanical

ENGINE OUTPUT

24HP

LUBRICATION

Fully pressurized

OIL FILTER

Yes

STARTER TYPE

Electric

 Cutting Deck

ANTI-SCALPING

Three-gauge wheels

BLADE(S)

Three

CUTTING HEIGHT RANGE

1″ – 4.75″

DECK CONSTRUCTION

Fabricated

DECK CUTTING WIDTH

60 in

DECK ENGAGEMENT (PTO)

Electric

DECK LIFT

Foot pedal with Dial Adjust

DECK MATERIAL

10-gauge steel with 2-gauge reinforcement

DECK POSITIONS

17

DECK WASH

No

 Comfort

ARMRESTS

Yes

SEAT ADJUSTMENT

Lever

SEAT TYPE

20″ high back

 Battery

BATTERY

210 CCA

BATTERY TYPE

AGM (Absorbent Glass Mat)

BATTERY VOLTAGE

12V

 Controls

BRAKES

Disc

CRUISE CONTROL

No

STEERING CONTROL

Steering Wheel

 Warranty

COMMERCIAL WARRANTY

4-year 800 hours

DECK SHELL WARRANTY

Lifetime limited

FRAME WARRANTY

Lifetime Limited

WARRANTY

4-year 800 hours

 Chassis

CORROSION PROTECTION

Yes

FRAME

1.5″ x 3″ tubular steel

REAR TOW HITCH

Yes

ROPS

Yes

TURNING RADIUS

0°

 Additional Specifications

CUP HOLDER

Yes

HEADLIGHT(S)

Dual-LED

HOUR METER

Yes

MODEL NUMBER

47RSCAB8010

MULCH KIT

Available separately

OPERATOR PRESENCE SYSTEM

Yes

PARKING BRAKE

Foot Controlled

 Disclaimers

SPECIFICATIONS

Specifications subject to change without notice and without incurring obligation. The products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.

 Drive System

DRIVE SYSTEM

Hydrostatic

FORWARD SPEED

8 MPH /12.9 km/h

REVERSE SPEED

3.5 MPH / 5.6 km/h

TRANSMISSION

Hydro-Gear ZT 3100

 Wheels

FRONT TIRES

13″x 6.5″-6″

REAR TIRES

22″x 12″-12″

TIRE TREAD

Turf Master / Multi Trac

 Specifications

SERIES

Ultima Series™ ZTXS
