Cub Cadet Ultima ZTXS 4 54 Zero Turn

Cub Cadet Ultima ZTXS 4 54 Zero Turn

Kohler Twin KT Pro 7000 Series/ 725cc

• Synchro-Steer™ technology offers 4-wheel control helps and provides stability for straight-line mowing on hillsides and slopes up to 20°

SPECIFICATIONS:

Engine

AIR FILTER

Dual element



CHARGING SYSTEM

12 amp regulated



CHOKE

Choke-a-matic



CYLINDERS

Twin



ENGINE BRAND

Kohler®



ENGINE DISPLACEMENT

725cc



ENGINE MODEL

Pro 7000 series



ENGINE MODEL NUMBER

KT735



ENGINE OIL CAPACITY

2.0 qt. US (1.89 L)



ENGINE START

Ignition Key



FUEL DELIVERY

Carburetor



FUEL GAUGE

Yes



FUEL TANK CAPACITY

5.5 gal. US (20.82 L)



GOVERNOR

Mechanical



ENGINE OUTPUT

24HP



LUBRICATION

Fully pressurized



OIL FILTER

Yes



STARTER TYPE

Electric



 Cutting Deck

ANTI-SCALPING

Three-gauge wheels



BLADE(S)

Three



CUTTING HEIGHT RANGE

1″ – 4.75″



DECK CONSTRUCTION

Fabricated



DECK CUTTING WIDTH

54 in



DECK ENGAGEMENT (PTO)

Electric



DECK LIFT

Foot pedal with Dial Adjust



DECK MATERIAL

10-gauge steel with 2-gauge reinforcement



DECK POSITIONS

17



DECK WASH

No



 Comfort

ARMRESTS

Yes



SEAT ADJUSTMENT

Lever



SEAT TYPE

20″ high back



 Battery

BATTERY

210 CCA



BATTERY TYPE

AGM (Absorbent Glass Mat)



BATTERY VOLTAGE

12V



 Controls

BRAKES

Disc



CRUISE CONTROL

No



STEERING CONTROL

Steering Wheel



 Warranty

COMMERCIAL WARRANTY

4-year 800 hours



DECK SHELL WARRANTY

Lifetime limited



FRAME WARRANTY

Lifetime Limited



WARRANTY

4-year 800 hours



 Chassis

CORROSION PROTECTION

Yes



FRAME

1.5″ x 3″ tubular steel



REAR TOW HITCH

Yes



ROPS

Yes



TURNING RADIUS

0°



 Additional Specifications

CUP HOLDER

Yes



HEADLIGHT(S)

Dual-LED



HOUR METER

Yes



MODEL NUMBER

47RSCAB7010



MULCH KIT

Available separately



OPERATOR PRESENCE SYSTEM

Yes



PARKING BRAKE

Foot Controlled



 Disclaimers

SPECIFICATIONS

Specifications subject to change without notice and without incurring obligation. The products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.



 Drive System

DRIVE SYSTEM

Hydrostatic



FORWARD SPEED

8 MPH /12.9 km/h



REVERSE SPEED

3.5 MPH / 5.6 km/h



TRANSMISSION

Hydro-Gear ZT 3100



 Wheels

FRONT TIRES

13″x 6.5″-6″



REAR TIRES

22″x 12″-12″



TIRE TREAD

Turf Master / Multi Trac



 Specifications

SERIES

Ultima Series™ ZTXS
