CUB CADET ULTIMA ZTX 6 60

CUB CADET ULTIMA ZTX 6 60

FEATURES:

• Thoughtfully designed 1.5 in. x 3 in. tubular steel frame provides optimal strength and rigidity while allowing accessibility for easy routine maintenance
• Commercial-grade 25.5 HP Kawasaki® FX801 V-Twin OHV engine for reliable starting and exceptionally smooth, quiet operation.
• Commercial-grade dual Hydro-Gear® ZT-3400 hydrostatic rear-wheel transmissions for quick and effortless up to 9 MPH forward and 3.5 MPH reverse zero-turn controlled ground speeds.
• Four-year/500 hour product warranty plus limited lifetime warranty on the frame and fabricated deck shell give you peace-of-mind
• Ideal for 4-12 acres with slightly rolling hills and several obstacles
• Financing Available

SPECIFICATIONS:

ENGINE

AIR FILTER

Dual element

BATTERY

12V 230 cold crank amps

CHARGING SYSTEM

15 Amp Regulated

CHOKE

Separate choke and throttle

CYLINDERS/MATERIAL

Twin

ENGINE BRAND

Kawasaki®

ENGINE DISPLACEMENT

852 cc

ENGINE MODEL

FX Series

ENGINE OIL CAPACITY

2.1 qts.

ENGINE START

Key

FUEL GAUGE

Fuel Gauge

FUEL TANK CAPACITY

5.5 gal.

GOVERNOR

Manual

ENGINE OUTPUT

25.5 hp

LUBRICATION

Fully pressurized

OIL FILTER

Yes

CUTTING DECK

ANTI-SCALPING

2 ball, 1 nose

BLADE(S)

3

CUTTING HEIGHT RANGE

1″ – 4.75″, 5″ transport

CUTTING MODES

Discharge/mulch/bagging

DECK ATTACH/REMOVAL

Removable

DECK CONSTRUCTION

Fabricated

DECK CUTTING WIDTH

60″

DECK ENGAGEMENT (PTO)

Pull knob (electric)

DECK LIFT

Foot pedal with Dial Adjust

DECK MATERIAL

10-gauge AeroForce Max” fabricated steel/double plate reinforced spindle mounts/ 7-gauge side wraps/skid plate

DECK POSITIONS

16 positions and transport position

SPINDLE CONSTRUCTION

Sealed cast aluminum housing (Maintenance free)

COMFORT

ARM RESTS

Included

FLOOR MATS

Rubber

SEAT ADJUSTMENT

Lever

SEAT SUSPENSION

Full Seat Suspension

SEAT TYPE

24″ high back seat

STEERING COMFORT

Quick adjustable (no tools) Soft Touch lab bars

ADDT’L SPECS

BAGGER

Optional

CUP HOLDER

Included

DISCHARGE CHUTE

Included

MULCH KIT

Optional

OPERATOR PRESENCE SYSTEM

Included

CONTROLS

BRAKES

Lap bar integrated

DISPLAY

Hour meter

HEADLIGHT(S)

2 – LED

STEERING WHEEL CONTROL

Lap bars

CHASSIS

CORROSION PROTECTION

Triple Guard Corrosion Defense System”

FRAME

1.5″ x 3″ tubular steel frame

FRONT AXLE(S)

Fabricated steel

FRONT TIRES

13″x 6.5″-6″

REAR TIRES

24″x 12″-12″

REAR TOW HITCH

Included

ROPS

Included

TIRE TREAD

Turf Master/Multi Trac

TURNING RADIUS

0″

YOKES

5/16 steel

WARRANTY

DECK SHELL WARRANTY

Limited lifetime warranty

FRAME WARRANTY

Limited lifetime warranty

WARRANTY

4-year/500 hour warranty

DRIVE SYSTEM

FORWARD SPEED

9 MPH

REAR AXLE

1.125″

REVERSE SPEED

3.5 MPH

TRANSMISSION

Hydro-Gear ZT 3400 Charged

TRANSMISSION HOUSING

Cast aluminum

TRANSMISSION TYPE

Hydro-Gear ZT 3400 Charged

SPECIFICATIONS

SERIES

Ultima Series ZTX
