• Thoughtfully designed 1.5 in. x 3 in. tubular steel frame provides optimal strength and rigidity while allowing accessibility for easy routine maintenance
• Commercial-grade 25.5 HP Kawasaki(R) FX801 V-Twin OHV engine for reliable starting and exceptionally smooth, quiet operation.
• Commercial-grade dual Hydro-Gear® ZT-3400 hydrostatic rear-wheel transmissions for quick and effortless up to 9 MPH forward and 3.5 MPH reverse zero-turn controlled ground speeds.
• Four-year/800 hour product warranty plus limited lifetime warranty on the frame and fabricated deck shell give you peace-of-mind
• Ideal for 4-10 acres with slightly rolling hills and several obstacles



SPECIFICATIONS:

Engine

Engine Brand

Kawasaki®

Engine Model

FX Series

Engine Model Number

801V

Engine Displacement

852cc

Engine Output

25.5HP

Starter Type

Electric

Fuel Tank Capacity

5.5 gal. US (20.82 L)

Cylinders

Twin

Engine Start

Ignition Key

Engine Oil Capacity

2.1 qt. US ( 2 L)

Lubrication

Fully pressurized

Charging System

15 amp regulated

Fuel Gauge

Yes

Governor

Mechanical

Choke

Separate Choke

Air Filter

Single element

Oil Filter

Yes

Fuel Delivery

Carburetor

Battery

Battery

230 CCA

Battery Type

Standard Lead-Acid

Battery Voltage

12V

Drive System

Transmission

Hydro-Gear ZT 3400 Charged

Forward Speed

9 MPH / 14.5 km/h

Reverse Speed

3.5 MPH / 5.6 km/h

Drive System

Hydrostatic

Cutting Deck

Deck Cutting Width

54 in

Deck Wash

No

Deck Material

10-gauge steel with 2-gauge reinforcement

Deck Engagement (PTO)

Electric

Deck Construction

Fabricated

Blade(s)

Three

Deck Lift

Foot pedal with Dial Adjust

Cutting Height Range

1″ – 4.75″

Anti-Scalping

Three-gauge wheels

Deck Positions

17

Warranty

Warranty

4-year 800 hours

Frame Warranty

Lifetime Limited

Deck Shell Warranty

Lifetime limited

Commercial Warranty

No

Chassis

Frame

1.5″ x 3″ tubular steel

Turning Radius

0°

ROPS

Yes

Rear Tow Hitch

Yes

Corrosion Protection

Yes

Controls

Cruise Control

No

Brakes

Disc

Steering Control

Lap Bars

Comfort

Seat Type

24″ high back

Armrests

Yes

Seat Adjustment

Lever

Wheels

Rear Tires

24″x 12″-12″

Front Tires

13″x 6.5″-6″

Tire Tread

Turf Master / Multi Trac

Additional Specifications

Hour Meter

Yes

Mulch Kit

Available separately

Headlight(s)

Dual-LED

Cup Holder

Yes

Operator Presence System

Yes

Parking Brake

Lap Bar Integrated

Model Number

47RIAHA7010

Specifications

Series

Ultima Series™ ZTX

Disclaimer

Specifications Disclaimer

Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
