Cub Cadet Pro Z 560 S

27 HP 852cc KW FX850v, 12cc PARKER HTJ, 60″ Fab Deck-Triple 7

• 3-year limited commercial warranty (no hour limitations)
• 27 HP Kawasaki FX850v (852cc) engine and 12cc Parker HTJ transmission
• 60” triple-7-gauge fabricated steel cutting deck with top, bottom and side reinforcements

EQUIPPED TO GET MORE DONE

Every part of the PRO Z 500 S was thoughtfully considered to maximize your work day. Bigger, faster engines and more fuel capacity means more cutting time and more acres mowed, every day.

MAXIMIZE YOUR WORKDAY

The steering wheel zero-turn option increases hillside stability, helping you cover acres up to 10% faster than comparable lap bar units. Other productivity-enhancing features optimize rear weight distribution, including pre-drilled mounting points for attachments and smart fuel pod placement.

BEST-IN-CLASS DECK

Stand up to the toughest conditions with the only commercial lawn mower touting a triple-7-gauge steel cutting deck made of 7-gauge top and bottom reinforcements, plus ¼˝ leading edge and 5/16˝ side reinforcements.

CUT DOWN JOB TIME

Finish the job efficiently with a 60˝ cutting deck option and twin fuel tanks that have a 14.9 gallon capacity.  High-performance Kawasaki® engines paired with commercial-grade 12cc transmissions provide optimal and consistent blade-tip speed.

ALL-DAY COMFORT

Ride in comfort on the standard high-back suspension seat with an angle-adjustment dial and additional customization controls for the perfect fit.

Specifications

MOWER DECK

BLADE-TIP SPEED (APPROX)

18,500 fpm

BOTTOM REINFORCEMENT

7ga. (.187″) bottom plate

ROLLED LEADING EDGE REINFORCEMENT

1/4″ (.250″) steel

SIDE CONSTRUCTION

5/16″(.313) steel on trim and discharge sides

SPINDLE COVERS

Steel – Tool-less Quick Release

TOP REINFORCEMENT(S)

7ga. (.187″) top plate

TRIM-SIDE WEAR GUARD

3/4″ Thick UHMW-PE Replaceable Trim-side Wear Guard

DECK MATERIAL

fabricated 7ga. (.187”) steel shell

ANTI-SCALPING

2 Front HD w/ Bushings & Grease Zerk

DECK BLADES

Triple-blade / High-lift blade (standard) Marbain Blade

DECK HEIGHT ADJUSTMENT

Foot pedal with spring assist
16 Positions

DECK SIZE/TYPE

60″ FABRICATED DECK

DECK STYLE/CONSTRUCTION

7ga. top plate
7ga. bottom reinforcement
¼” rolled leading edge

DISCHARGE CHUTE

Heavy-duty Flex chute (impact resistant)

CUTTING HEIGHT

1″ – 5″

GENERAL

CRUISE CONTROL

N/A

CUP HOLDER

Integrated into Side Pod

FRONT TIRES

13″ x 6.5″ – 6″ (turf tread)

FRAME

Fully welded, full-length 3/8 x 5″ laser cut steel / integrated tie-down slots

FRONT AXLE / YOLKS

2″ x 3″ solid axle tube and 1/2″ thick steel front yokes

LENGTH / WIDTH / HEIGHT*DISCHARGE CHUTE UP WIDTH*ROP’S UP HEIGHT

80″ L x 50″ W x 58″ H

PTO CLUTCH

Warner Clutch – 125 ft. lb.

PARK BRAKE / BRAKING

Hand-operated lever with integrated hydro pump release lever

ROPS

2″x2″ Foldable 3 Position Low Profile Clearance

REAR BUMPER

5/16″ Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch

REAR TIRES

24″ x 12″ – 12″ (Turf Tread)

SEAT TYPE

High-back dial suspension with EVC cushion, seat belt, angle back adjust, arm rests

THROTTLE/PTO/KEY SWITCH

HD Low-profile throttle lever, sealed key switch & electronic fingertip engagement pto

WEIGHT (APPROX)

1060 LBS.

HOUR METER

Standard electronic

SAFETY SYSTEMS

Operator presence

ENGINE & DRIVE SYSTEM

ENGINE TYPE

Kawasaki FX850v

FUEL CAPACITY

Twin 7.45 gal. tanks (14.9 gal. total) with dial gauge

HORSEPOWER / CC’S

27hp – 852cc

GROUND SPEED

Fwd: 10 mph/Rev: 5 mph

TRANSMISSION

Parker HTJ Series
12cc pump / 260cc wheel motor

STEERING



STEERING WHEEL CONTROL

High Performance Steering Wheel & Foot-pedal Control

STEERING WHEEL ADJUSTMENT

Multi-position Quick-adjust steering column

POWER STEERING

Standard

SPECIFICATIONS

WARRANTY

3 year / no hour limit commercial warranty
