Centurion 1.32M Flail Mulching Mower Manual Side Shift

Del Morino Centurion 132 Flail Mulching Mower Manual Side Shift

Del Morino Srl manufactures agricultural equipment in Italy since 1875 and is one of Europe’s most renowned manufacturers of agricultural attachments.

OVERVIEW

The Centurion 132 Flail Mulching Mower is ideal for Compact Tractors up to 30 HP. There is a manual side shift fitted to adjust offset for challenging terrain. This trusted Italian-made flail mower, combines quality with high performance and light operating weight ideal for modern compact tractors. This size would be suitable for the likes of Kubota BX2380 BX2680 , John Deere 1023e 1025R Series , Kioti CS2610

FEATURES AND BENEFITS

-3 point Hitch Category 1 with manual side shift

-Cast Iron Gearbox 540 RPM with a freewheel overrun

-2 Belt drive with screw adjustable tensioner which is very easily adjusted by a bracket + clamping screw.  V-belt tension is very easy to access.

-Electronically balanced Rotor with 10 mm wall thickness for high operating speed with minimal vibration

Fitted with 20 Hammer flails of 800 gr each flail is capable of shattering branches up to 3 – 4 cm due to the impact mass but also gets a very nice clean cut on grass due to the straight cutting edge and high rotor speed.

-Adjustable rear levelling roller, The cutting height can be adjusted via the rear levelling roller (runs in greaseable flange bearings).

-Front metal flaps for protection from stones or debris

-PTO Shaft (series 4) Supplied

Offset measurements

In the central position, it has 650mm to left from the centre and 850mm from right to the centre of the tractor

Offset left,  510mm left to centre 990mm right to the centre of the tractor

Offset Right 790mm to left of centre 710mm right from the centre of the tractor

2 Year Warranty

Specifications	Units
Cutting Width	1320mm
Overall Width	1500mm
Cutting Height	30-100mm
Gearbox	540 RPM
Rotor Speed	2410 RPM
Number of Hammers	20 hammer flails
Tractor Connection	Category 1, 3-point linkage
Side Thickness	5mm
Frame thickness	3mm
Rotor	89mm diameter x 8mm thickness
Rear Roller	127mm diameter x 4mm thickness
Tractor HP	20-30 HP for 132
Belts	2 x Optibelt Red Power 3  SPB1250
Weight	235kg
