Features:
- Control the output of the chipper with the easily adjustable chute allowing the user to direct the flow of chips where they want.
- Angling the log against the rotor requires less horsepower to chip, saving fuel.
- With Wallenstein you have a choice. Products are available in seven solid colors as well as Realtree EDGE™ and Realtree EDGE™ Shadows camouflage. $250 price premium for Realtree camouflage.
- Reliable and convenient starting at the turn of a key.
- Transport your unit with hitch, safety chains, highway tires, and full trailer lighting.
- Extra large chipper intake backed up by extra large rotor spinning with high momentum.
- The discharge chute is equipped with a positional discharge deflector on the end of the chute to direct the chips exactly where desired.
- Standard reversible rotor knives double the longevity of your knives.
- The self-feed hopper takes advantage of gravity and an optimized knife angle to pull branches in as it chips.
- Axles are designed to absorb road impact, providing a smoother towing experience.
- The discharge paddle passes around the twig breaker and helps to break the material into smaller pieces and turn it into mulch.
Chipping Capacity: | 5″ (12 cm) |
---|---|
Chipper Type: | Disc |
Feed System: | Gravity |
Engine: | Vanguard® 23 hp (627 cc) EFI |
Chipper Hopper Opening: | 24.5″ x 20″ (62 cm x 50 cm) |
Chipper Rotor Opening: | 5″ x 10″ (12 cm x 25 cm) |
Number Of Chipper Knives: | 2 |
Rotor Diameter: | 25″ (63 cm) |
Rotor Weight : | 170 lb (77 kg) |
Discharge Chute Height: | 69″ (175 cm) |
Discharge Chute Rotation: | 295° |
Drive System: | Centrifugal Clutch, Belt Drive |
Engine Speed: | 3600 RPM |
Rotor Speed: | 2000 RPM |
Tires: | 5.30 x 12 |
Tongue Weight: | 75 lb (34 kg) |
Total Weight: | 1035 lb (469 kg) |
Dimensions (LxWxH): | 134″ x 47-3/4″ x 70″ (340 cm x 120 cm x 177 cm) |
Fuel Tank Capacity: | 7.04 US gal (26.6 L) |
