Any Airless to AAA Upgrade Kit with VIPER® Gun

Any Airless to AAA Upgrade Kit with VIPER® Gun

Manufacturer: Total Finishing Supplies

Part Number: ViperKit

Description: Upgrade any airless system to an air-assisted airless system with a VIPER® gun!

Kit Includes:

• VIPER® Gun with choice of Tip (VIPER-XX-XXX)
• Air Compressor (CAT-4620AC)
• 25′ – 3/16″ TFS Fluid Hose with 1/4″ Female Stainless Steel Fittings (TF-PA13-25FFSS)
• 25′ – 1/4″ TFS Air Hose with 1/4″ Female Fittings (TFS1511-4634-25)

The VIPER® manual spray gun uses our Mix Tech spray technology to provide you with exceptional atomization, performance, value, durability, and finish quality.  VIPER® is constructed with our aftermarket parts (Non-OEM) manufactured for the KREMLIN® Xcite® gun. The VIPER® spray gun boasts an 86% transfer efficiency. The VIPER® Mix Tech competes with other much higher-priced European Air Assisted Airless spray guns. VIPER® can be used with water-based or solvent-based coatings with fluid pressures up to 120 bar (1,740PSI).

Features:

• Material savings & environmental protection
• VIPER® is manufactured by an ISO9000 facility
• HVLP compliant
• Unsurpassed atomization and quality of spraying at almost half the price
• Lightweight and ergonomic design for outstanding performance
• Performance comparable to KREMLIN® Xcite® and uses our Non-OEM Aftermarket Standard and Ultra Fine Finish tips, seals, air cap, diffuser, fluid needle and spray gun filter screens

The California Air Tools 4620AC is our ultimate portable compressor!  It runs at 7.0 CFM at 40 PSI.  Designed to be one of the quietest 2.0 hp air compressors in the industry, the 4620AC only has 70 decibels of sound.

• 7.0 CFM at 40 PSI
• 120 volts
• Continuous duty cycle

Air Compressor Specifications:

Fluid Inlet: NPSM 1/4″
Compressed Air Connection: NPT 1/4″
Max Inlet Pressure: 8.62 BAR / 116 psi
Weight: 64.0 lb (29.0 kg)
Max Sound Level:  70dB

Total Finishing Supplies offers two types of 3/16” high-pressure airless paint sprayer hose. Both have great flexibility and can typically be seen applying spray coatings such as stains, lacquers, and oil-based paints. Our 25-foot high-pressure airless paint hose rated at 3,500 PSI is one of the most popular hoses equipped on an air-assisted airless paint sprayer.



Literature

• OPERATING MANUAL

• CUT SHEET

• BROCHURE

• TIP CHART



Accessory Part List

• Non-OEM Standard Tips 134-5xx-xx4 or 134.5xx.xx4

• Non-OEM Ultra Series Fine Finish Tips 134-5xx-xx2 or 134.5xx.xx2

• Non-OEM VX24 Air Cap 132-720-020 or 132.720.020

• Non-OEM Aftermarket Tip Sieve (gun filter) Support 129.609.90X

• Non-OEM Aftermarket Replacement Gun Filters (select mesh) 129.609.90X

• Non-OEM Aftermarket 140 & 200 Mesh Tip Sieves 129.609.90X

• 60 Bar Spring
• 120 Bar Spring
• 200 Bar Spring

• 1/4″ NPT Female x #5 JIC Male

• 1/4″ M x 1/4″ F Swivel

• 3/16″ High-Pressure Fluid Line (select fittings when ordering)

• 25′ Air Line

Replacement Part List:

• 2. Wedge

• 3. Fan Regulation Set

• 4. Pressure Wedge

• 5. Fluid Needle Gasket

• 6. Fluid Needle Screw

• 7. Air Valve Complete

• 8. Needle Set*

• 9. Air Valve Spring

• 10. Needle Spring

• 11B. Back Cap

• 12. Air Inlet 1/4”

• 13. Pin

• 14. Safety Lock

• 15. Trigger Pin

• 16. Trigger

• 17. Sealing Gasket

• 18. Gun Head / Diffuser Set

• 18-2. Sleeve Gasket / Diffuser Seal

• 23-1. Mix Nozzle Standard

• 23-2. Air Cap Gasket, 2/pkg

• 23-3. Air Cap (Non-OEM KREMLIN® VX24)

• 24-1 Pre-Atomized Nozzle (Ultra Tips)
• Aftermarket KREMLIN® Compatible O-Ring Teflon Tip Seals (10 pk)
• Diffuser O-Ring (10 pk)
• 120 Bar Needle Kit, Complete

*= Included in 120 Bar Needle Kit, Complete

NO DISCOUNT CODES may be applied to this item

NOTES:

KREMLIN®, AIRMIX®, and Xcite® are registered trademarks of Sames Kremlin SA or Exel Industries SA, and the same companies may claim unregistered trademark rights in other words. The advertised parts are intended to fit KREMLIN® and Xcite® spray equipment. They are not, however, manufactured, endorsed, or sponsored by Sames Kremlin SA or Exel Industries SA or any of their affiliates, and no warranty by Sames Kremlin SA, Exel Industries SA, or any of their affiliates applies. Total Finishing Solutions, LLC is not affiliated with or sponsored or endorsed by Sames Kremlin SA or Exel Industries SA and is not one of their authorized distributors.

Click here to view other products, parts, & accessories!

Warranty:

1 year MFG warranty from MFG defect.



 Comparable to:

668-720-100 668.720.100

668-720-400 668.720.400

668-720-900 668.720.900

668-720-901 668.720.901

668-720-401 668.720.401

668-720-402 668.720.402

668-720-425 668.720.425

668-720-450 668.720.450

668-720-125 668.720.125

668-720-150 668.720.150

668-720-300 668.720.300

668-720-302 668.720.320

668-720-800 668.720.800

668-720-225 668.720.225

668-720-250 668.720.250

668-720-275 668.720.275
